Name: SwimClear Multi-Element Cartridge Filter 525 Sq.Ft.
SKU: C5030
Availability: InStock

Características

Con un clúster de cartuchos reutilizables, los filtros SwimClear ofrecen una opción de 225, 325, 425, 525 o 725 pies cuadrados de capacidad de retención de suciedad de alta resistencia para ciclos de filtro extralargos, hasta una temporada completa sin necesidad de limpieza. Los filtros SwimClear proporcionarán años de funcionamiento sin problemas, además de agua cristalina y brillante

Características y beneficios

La válvula de salida de aire manual de gran capacidad y de rápida liberación expulsa el aire con un rápido giro de un cuarto de vuelta de la palanca
Tanques de filtro confeccionados en un copolímero de vidrio reforzado duradero para satisfacer las exigencias de las aplicaciones y las condiciones ambientales más difíciles, como los sistemas de limpieza en aplicaciones enterradas
Self-aligned tank top and bottom make access to service the Quad-Cluster™ cartridge elements fast and simple
La abrazadera de una pieza, que es extrafuerte y a prueba de manipulación, sujeta firmemente las partes superior e inferior del tanque. Permite acceso rápido a todos los componentes internos sin alterar las tuberías o conexiones
La configuración del múltiple superior ofrece excelente filtración y rendimiento hidráulico
La placa de cierre superior no corrosiva evita que los elementos se levanten y permite que el agua sin filtrar se desvíe hacia la piscina o el spa durante el funcionamiento
El sistema Quad-Cluster de cartuchos de poliéster de alta calidad proporciona 225, 325, 425, 525 o 725 pies cuadrados de área de filtro para brindar capacidad adicional de retención de suciedad y ciclos de filtro largos
Tuberías internas de flujo completo de 2 in para ofrecer menor resistencia al flujo y máximo rendimiento
La conexión de acoplamiento de unión de PVC admite tuberías de 2 in o 2 1/2 in para brindar versatilidad y eficiencia hidráulica
El drenaje integral de tamaño completo de 1 1/2 in permite un lavado más fácil y rápido del tanque

Los productos EXPERT LINE solo pueden comprarse a través de tu profesional de piscinas o tienda local. Se pueden aplicar exclusiones y otros términos y condiciones.
Garantías de piezas y mano de obra de más de 3 años*

* Cuando lo vende un socio Hayward Rewards®. Se pueden aplicar exclusiones y otros términos y condiciones.

Certificación de NSF

Los servicios integrales de inspección, pruebas y certificación de NSF garantizan que nuestros productos cumplan con todos los principales códigos de salud estatales y provinciales, así como con los códigos de construcción y construcción de modelos.

Aplicación	Construcción nueva, renovación
Marca	Hayward
Cartucho	Sí
Canal	Línea Expert
Diseño de tasa de flujo	150
Tamaño del puerto de drenaje (pulgadas)	1.5
Área de filtración eficaz	525 ft²
Tipo de filtro	Cartucho
Superficie	26 x 26 IN
GTIN	610377123976
Warranty - Labor	1 año
Cantidad de caja a granel	1
Cantidad de elementos filtrantes	4
Cantidad por palé	8
Warranty - Parts	3 años
Tipo de piscina	Para piscinas enterradas
Manómetro	Sí
Dimensiones del producto	46.5 in x 24 in x 24 in
Altura del producto	46.5 in
Longitud del producto	24 in
Peso del producto	79 lb
Ancho del producto	24 in
Caudal de diseño público	150 g. p. m.
Cantidad	1
Caudal de diseño residencial	150
Series de productos de filtros	SwimClear: multielementos
Dimensiones del envío	47.8 in x 24.6 in x 23.1 in
Pesos de envíos	92 lb
Espacio libre lateral - Filtros	18 in
Submarca	N/D
Tipo de tanque	GFR
Rendimiento - 10 horas	90,000 g. p. m.
Rendimiento - 8 horas	72,000 g. p. m.
Válvula incluida	N/D

Questions & Answers

11 answered question(s)

William Verified User

06/24/26

Q: What size cartridge filter for a 40000 gallon inground pool?

A:

Hi, filtration needs vary with location, and bather load. Contact a local Hayward Authorized Dealer for further assistance in choosing the right filter for your location. You can find a list of them by clicking on the Dealer Locator tab on the home page...

By Hayward Support

Yomaira F Verified User

06/24/26

Q: I have a C4030 29k gallon pool. I feel the filters are too small for my pool they are always dirty. I would like to know what system is better for my pool.

A:

Hi, filtration needs vary with location, and bather load, but in general a C4030 should be adequate. Contact a local Hayward Authorized Dealer for further assistance in choosing the right filter for your location. You can find a list of them by clicking...

By Hayward Support

Richard Verified User

06/24/26

Q: I got a swim clear filter assembly C4530Bhmb needing 4 filters for it will C 4030 work

A:

Hi, you need CX875XRE elements.

By Hayward Support

Mike P Verified User

06/24/26

Q: I'm trying to replace a (non-DE) filter cartridge tank head. The old label came off but it's a 525SF, quad-element tank, which appears to be in the C5030 line. Can you confirm if the DEX6020BTC is the correct replacement head?

A:

That would be the correct part for a C5030

By Hayward Support

Aaron Verified User

06/24/26

Q: I am wanting to convert from a sand filter to a cartridge type. I currently have a S244T sand filter. What cartridge type would be equivalent?

A:

Hi, filtration needs vary with location, and bather load, but in general a C150S should be adequate. Contact a local Hayward Authorized Dealer for further assistance in choosing the right filter for your location. You can find a list of them by clicking...

By Hayward Support

Alan Hildebrand Verified User

06/24/26

Q: What size cartridge style filter for 26,000 pool

A:

Hi, with a properly sized pump the C200S single element cartridge filter would work fine, or for a multi element version you could go with a C2030 or larger. The multi element models will not require cleaning as often.

By Hayward Support

Thom Arrendale Verified User

06/24/26

Q: 10 yr old system and control panel has gone out! Need replacement?

A:

Hi, someone from our Technical Service Department will contact you via email.

By Hayward Support

Tracey T Verified User

06/24/26

Q: I am looking to replace filter and pump would like carteige filter and also want to switch to slat water and my pool is -16x34 and 12,000 gallons just not sure what size system i need

A:

These are questions best answered by your local Hayward Authorized Dealer. You can find a list of them by clicking on the Dealer Locator tab on the home page of our website Hayward.com

By Hayward Support

Bill Pawlo Verified User

06/24/26

Q: I am looking at your product descriptions on line for the Swimclear Multi Element Cartridge Filter # C5030. I am confused. The description for the "filer" reads as follows SwimClear single element cartridge filters capture more dirt for superior water clarity without the need of supplemental media or backwashing, while the industry's lowest head loss reduces energy costs. Is it a multi element cartridge or a single element one ??? WHAT'S THE DIFFERENCE ?? I would rather have more filtering capacity than less is this an appropriate filter for my pool ?? The information provided also references "smaller and mid sized pools", I have an inground 36,000 gallon pool. (20 X 40) What is that considered. I have a Hayward sand filter now but am considering changing it. Please advise

A:

Hi, thank you for bringing this to our attention. Our web team will have this corrected soon. As to how big a filter you need? We leave that to the pool professionals in your area. You can find a list of them on our website by clicking on the Dealer ...

By Hayward Support

Mark Coopersmith Verified User

06/24/26

Q: I have a C5030 filter, I seem not to be able to purchase filters for it. All the ones I order that say for Hayward c5030 are coming to tall. The all measure abut 33 inches, mine are about 31 inches. So if I try to out them in the lid won’t go on. What can I do

A:

HI, the CX1280XRE or CX1280XREPAK4 are the cartridges designed for the C5030 filter. If those do not work, contact a local Hayward Authorized Service Center. You can find a list of them by clicking on the Dealer Locator tab on the home page of our website...

By Hayward Support

AJ Verified User

06/24/26

Q: What size pool filter is recommended for a 55k in ground pool?

A:

Hi, someone from our tech support group will be in touch via email.

By Hayward Support
