Name: SwimClear Single Element Cartridge Filter 200 Sq.Ft.
SKU: C200S
Availability: InStock

Características

La incorporación más reciente a la familia SwimClear es simplemente el filtro de un solo cartucho más eficiente. Captura más suciedad para ofrecer mayor claridad del agua, y la pérdida de carga más baja de la industria puede aumentar el ahorro de energía. SwimClear es el más fácil de mantener: el diseño del anillo Easy-Lok™, los mangos de agarre cómodos y la altura de elevación más baja ofrecen una limpieza y reemplazo de filtros más rápidos. Para ahorrar energía, obtener un rendimiento confiable y maximizar la facilidad de servicio, la opción es clara como el agua: SwimClear.

Características y beneficios

Captura más suciedad para una mayor claridad del agua sin necesidad de medios complementarios
La eficiencia hidráulica líder de la industria permite que la bomba funcione a una velocidad más baja y durante menos tiempo, lo que aumenta el ahorro de energía
El diseño del anillo Easy-Lok permite un rápido acceso a todos los componentes internos para un mantenimiento sencillo y rápido
Los mangos ergonómicos proporcionan múltiples ubicaciones de manipulación sin tocar la fibra de vidrio para facilitar la instalación y el mantenimiento
Altura del cuerpo más baja, de manera que los elementos estén elevados para que la limpieza y el reemplazo sean cómodos y rápidos
El manómetro empotrado y la salida de aire manual permiten al usuario colocar el ensamblaje del cabezal al revés sobre el panel de control para piscina, protegiendo el sellado de la contaminación
Las conexiones de la unión de 2 in x 2 1/2 in hacen que la instalación y el mantenimiento sean rápidos y sencillos

Los productos EXPERT LINE solo pueden comprarse a través de tu profesional de piscinas o tienda local. Se pueden aplicar exclusiones y otros términos y condiciones.
Garantías de piezas y mano de obra de más de 3 años*

* Cuando lo vende un socio Hayward Rewards®. Se pueden aplicar exclusiones y otros términos y condiciones.

Certificación de NSF

Los servicios integrales de inspección, pruebas y certificación de NSF garantizan que nuestros productos cumplan con todos los principales códigos de salud estatales y provinciales, así como con los códigos de construcción y construcción de modelos.

Aplicación	Construcción nueva, renovación, mercado de posventa
Marca	Hayward
Cartucho	Sí
Canal	Línea Expert
Diseño de tasa de flujo	120
Tamaño del puerto de drenaje (pulgadas)	1.5
Área de filtración eficaz	200 ft²
Tipo de filtro	Cartucho
Superficie	18 x 18 IN
GTIN	610377269476
Warranty - Labor	1 año
Cantidad de caja a granel	1
Cantidad de elementos filtrantes	1
Cantidad por palé	8
Warranty - Parts	3 años
Tipo de piscina	Para piscinas enterradas
Manómetro	Sí
Dimensiones del producto	38.75 in x 18.25 in x 18.25 in
Altura del producto	38.75 in
Longitud del producto	18.25 in
Peso del producto	40 lb
Ancho del producto	18.25 in
Caudal de diseño público	75 g. p. m.
Cantidad	1
Caudal de diseño residencial	120
Series de productos de filtros	SwimClear de un solo cartucho
Dimensiones del envío	40.1 in x 18.7 in x 18.7 in
Pesos de envíos	40 lb
Espacio libre lateral - Filtros	18 in
Submarca	N/D
Tipo de tanque	GFR
Rendimiento - 10 horas	45,000 g. p. m.
Rendimiento - 8 horas	36,000 g. p. m.
Válvula incluida	N/D

Questions & Answers

13 answered question(s)

Lisa Weston Verified User

06/24/26

Q: We have a Hayward Pool Pump System. Do you sell filter cartridges for C200S (CX200XRE) Hayward pool equipment? If not, do you know where I can find one or order one from. If so, how much are they? Thank you!

A:

We do not sell direct, but you can find a list of local Hayward Authorized Dealers by clicking on the Dealer Locator tab on the home page of our website Hayward.com

By Hayward Support

Mrs chapelin Verified User

06/24/26

Q: Hello, where can I find this part or only the base ? My zip code is 33463 . I need help please

A:

Hi, you can find a list of local Hayward Authorized Dealers by clicking on the Dealer Locator tab on the home page of our website Hayward.com

By Hayward Support

Ralph Forbes Verified User

06/24/26

Q: how do i find replcement collar for this pool filter

A:

Hi, contact a local Hayward Authorized Dealer in your area for help with this. You can find a list of them by clicking on the Dealer Locator tab on the home page of our website Hayward.com

By Hayward Support

Fernando Verified User

06/24/26

Q: Debrief on Passing the Hayward Filter S200 I vacuumed the swimming pool, and all the dust and debris were removed. The pool remained clean until the next day when debris appeared again. I am 99% sure that the debris is coming from the filter.

A:

It sounds as if you may have a cracked lateral assembly. For help with this contact a local Hayward Authorized Service Center. You can find a list of them by clicking on the Dealer Locator tab on the home page of our website Hayward.com

By Hayward Support

Billy Gent Verified User

06/24/26

Q: The red release handle does not disengage to open my filter. Options?

A:

Hi, for help with this contact a local Hayward Authorized Service Center. You can find a list of them by clicking on the Dealer Locator tab on the home page of our website Hayward.com

By Hayward Support

David Verified User

06/24/26

Q: Hello, Lately my salt water generator union screen has been getting clogged with small debris which should be getting caught by the filter. I have a Hayward C150s swimclear cartridge filter using a Cryspool filter from amazon. The filter itself seems ok and is only a few months old, i dont see any tears or holes when inspecting it. So I'm thinking maybe the filter isnt seated correctly? Or there is a leak where the bottom of the filter meets the diffuser assembly? I see water coming out of the bottom when i fill it with a hose, is that a sign of a problem? I removed the diffuser assembly and it also seems ok but not sure what I should be looking for.

A:

Hi, beyond recommending you only use a Hayward replacement cartridge, this would be very difficult to diagnose remotely. We suggest contacting a local Hayward Authorized Service Center for assistance. You can find a list of them by clicking on the Dealer...

By Hayward Support

Debi Verified User

06/24/26

Q: How many gallons does this treat. My pool is 14x22 3' to 5'

A:

HI, the C200S cartridge filter should work fine for a pool of this size, but bather load and environmental conditions play a major part in the filtration requirements for a pool. We suggest you contact a local Hayward Authorized Dealer for help in sizing...

By Hayward Support

Joseph DAGOSTINO Verified User

06/24/26

Q: I have a 2 hp pump, and a 52" 24 round above ground pool. What is the right cartridge filter to purchase?

A:

HI, this question is best answered by a local Hayward Authorized Dealer. You can find a list of them by clicking on the Dealer Locator tab on the home page of our website Hayward.com.

By Hayward Support

Scott Verified User

06/24/26

Q: Why is this picture not the SwimClear C200S filter? Can’t find the single element SwimClear filters anywhere

A:

Hi, thank you for pointing this out to us! I have alerted our web team to get the correct picture on the page.

By Hayward Support

Scott Verified User

06/24/26

Q: Why is the picture on your website of a multi cartridge swim clear filter instead of the single cartridge filter

A:

Hi, thank you for bringing this to our attention. I will alert the correct department and we will get this corrected.

By Hayward Support

David Verified User

06/24/26

Q: Is the diffuser in the C100S filter and C200S filters the same? Or is the diffuser in the C200S longer? Same question for the bottom filter housing. Is it the same for both filter heads?

A:

Hi, the diffuser for the C100S and the C200S are different lengths to accommodate the different lengths of the cartridge. The bottom filter housing is the same for both.

By Hayward Support

David Verified User

06/24/26

Q: What is the circumference of the S-100 and S-200 filters

A:

HI, the circumference of the C100S and C200S are the same. Approx. 56.5 in

By Hayward Support

Ricardo Morales Verified User

06/24/26

Q: What cartridge filter size I need for an inground 15,000 gals. Pool.

A:

Hi, someone from our Technical Service Department will be in touch via email soon.

By Hayward Support
